Specs
Number of memories
100
Sampling frequency
44.1 kHz
Signal processing
32-bit float
Number of recording and playback tracks
1
Data format
WAV (44.1 kHz, stereo, 32-bit floating point)
Maximum recording times
90 minutes (1 loop) / 13 hours or more (total for all memories)
Frequency response
20 Hz - 20 kHz (+0.5 dB/-0.5 dB) (when 10kΩ load)
Display
160x128 dot-matrix LCD with color backlight
Inputs
L/R
Standard mono phone jacks
Rated input level: -20 dBu
Input impedance (line): 470 kΩ
Outputs
L/R
Standard mono phone jacks
Maximum output level: +7.2 dBu (when output impedance 10 kΩ or higher)
MIDI IN/OUT jacks
Stereo mini jack
Input S/N
122 dB
Noise floor (residual noise)
-100 dBu
Power
AC adapter
9V DC 500mA center negative (ZOOM AD-16)
2 AA batteries
Alkaline, Lithium or Rechargeable NiMH batteries
• USB bus power is supported.
Estimated operation times using batteries
Alkaline batteries
About 4.0 hours (about 3.5 hours using stereo input)
NiMH batteries (1900 mAh)
About 5 hours (about 4.5 hours using stereo input)
Lithium batteries
About 9 hours (about 8 hours using "stereo input)
• These values are approximate. • Battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.
USB
Port
USB 2.0 Type-C
Supported cable type
Type-C
USB MIDI
USB1.1 Full Speed
File transfer
USB 2.0 High Speed
• Use a USB cable that supports data transfer.
Dimensions
133 mm (D) x 79 mm (W) x 61 mm (H)
Weight
367 g (excluding batteries)
414 g (including batteries)
Note: 0 dBu = 0.775 V
